Filter SATA 584 SAT1099953

SATA®filter 584®| 3-stage combination filter – SAT1099953

The SATA filter 584 boasts a higher absorption of contaminations (compared to SATA filter 484) due to the new sintered activated charcoal filter

• Air flow with 4 connections approx. 3,800 Nl/min (135 cfm)
• SATA filter timer to monitor the exchange intervals of all filter cartridges
• Synchronized maintenance: Filter maintenance only necessary every 6 months for all stages
• Maintenance-free bayonet lock with haptic and acoustic feedback
• Fine filter and activated charcoal filter cartridges fit perfectly by being simply inserted – without screw fittings or additional seals
• CCS color coding of filter housing and filter cartridges for safe maintenance.
• Upgrade of a SATA filter 544 to a 584 possible through a simple connector system
• Maintenance-free sealing elements
• Line connection optionally left or right
• Flow-optimized cyclone separator with enhanced particle separation efficiency (approx. 10%) of particles > 5 µm (microns)

99.998 % technically particle-free air

Filter fineness:

• Sintered filter: 5 µm (microns)
• Fine filter: 0.01 µm (microns)
• 100 % technically particle-free air
• Activated charcoal filter: oil vapors
• Air flow at 6 bar (87psi): 3,800 Nl/min (135cfm)

Ambient temperature:

• 120 °C (240 ° F); with activated charcoal filter up to 60 °C (140 ° F)

Connection:

• Air inlet: G 1/2″ female thread
• Air outlet: 1/4″ male thread

Recommended for:

• solvent-based paints
• waterborne paints
• breathing protection equipment

Product Benefits:

• Higher absorption of contaminations (compared to SATA filter 484) due to the new sintered activated charcoal filter
• Synchronized maintenance: Filter maintenance only necessary every 6 months for all stages
• Maintenance-free bayonet lock with haptic and acoustic feedback
• Fine filter and activated charcoal filter cartridges fit perfectly by being simply inserted – without screw fittings or additional seals
• Upgrade of a SATA filter 544 to a 584 possible through a simple connector system
• Maintenance-free sealing elements, no o-ring replacement during maintenance
• Filter package is completely reversible to accommodate different filtration unit locations in booth
• Line connection optionally left or right
• Air regulator placed on air exit side resulting in better air flow and less loss of air efficiency
• Air flow at 6 bar (87psi): 3,800 Nl/min (135 cfm)
• Improved cfm output results in the capability of providing clean air to 4 painters, supplying spray guns and SATA Air Vision 5000 fresh air systems without loss or reduction of compressed air
• Improved water cyclone device resulting in a more consistent air flow
• Standard auto drain feature on models with sintered filter
• Color coded canisters to match filter colors (yellow; sintered filter, blue; fine filter, black; activated charcoal filter)
• Improved charcoal filter – new and improved sintered charcoal filter which does not break down as quickly as previous charcoal filter, with an improved replacement schedule of 6 months as opposed to 3 months on the previous model
• Improvements on filter canister connections providing easier filter replacement
• 99.998 % technically particle-free air
• Easily wall mountable
• Accessory port for CO2 monitor
• SATA adam 2 digital pressure gauge capability
